Cal-Mate 3204 is a rugged 100 mm digital pressure gauge for field measurement, maintenance, calibration and leak testing. Its clear
LCD combines a five-digit primary display, an integral bar graph and a secondary text area for efficient interpretation at the point of
use.
Three accuracy classes – 0.05% FS, 0.1% FS and 0.25% FS – allow the instrument to be matched to application requirements. The
rotatable display, 19 selectable pressure units and MIN/MAX recording simplify day-to-day operation. Optional Bluetooth
communication, optional RS485 output, AAA or rechargeable power, multiple process connections and OEM configuration support a
broad range of service and industrial workflows.
Applications
- Oil and gas industry
- Maintenance and service facilities
- Calibration service companies
- Test bench and gauge repair facilities
- Leak testing
- Portable field measurement
Special Features
- Rugged 100 mm metal housing
- Accuracy classes down to 0.05% FS
- 19 switchable pressure units
- Integral bar graph and large LCD
- MIN/MAX value recording
- 330 degree axial display rotation
- Bluetooth and RS485 options
- IP65 enclosure rating
